100Kg/h Small Laundry Soap Machine

100Kg/h Small laundry soap making machine Laundry soap production line starting with soap noodles as raw material Small scale soap making machine, suits the starter who want to invest soap factory Integrated machine design, takes small area to install the machines

Send Inquiry

Description

Introduction of 100Kg/h Small Laundry Soap Machine

This laundry soap machine is a laundry bar soap finishing line designed to make laundry soap bars and the soaps for laundering and washing clothes, which use soap noodles and other ingredients as raw material, designed capacity is 100-150Kg/h for finished laundry soaps. From this production line can make various sizes and shapes medium and high grade laundry soaps which have TFM (totally fatty acid) contain from 35% to 72%.

This is an integrated machine which designed the mixer, three roller mill and plodder in one machine equipped with stair, so that to loading the raw materials easily, mixing the raw materials together uniformly, milling the mixed raw materials and then extruding soap bar from one machine, after the soap bar extruded from plodder, use laundry soap cutting machine press logo on soap bar and then cut the soap bars to each laundry soaps.

Main raw material: Soap Noodles

Ingredient: Caustic soda, Zeolite, Perfume, Pigment or the ingredients according to buyer's formula

Water: Water circulating in inter layer of augers on duplex vacuum plodder to cooling the machines

Installed power: 17.4Kw, electricity consumption about 10-15Kw.h

Installation size: 10x5x4 meter (LxWxH)

Labor required: 3-4

100Kg/h Small Laundry Soap Machine Equipment list and Technical Data

1. Soap Bar Extruding Unit

Complete unit is combined by Mixer + Three Roller Mill + Extruding Plodder + Stairs, the function is to mixing raw materials, milling raw material and extruding raw material to soap bar

Mixer model WJ600, capacity: 75Kg/batch

Mix Soap noodles with ingredients together evenly, uniformly and sufficiently

Each mixing batch takes 5-6 minutes. Motor 2.2Kw

Three Roller Mill model SG150, capacity 100-200Kg/h

Milling and refining soap noodles to schistose, to improve fineness and milling the mixed raw materials more evenly thus to make soap bar more tighten and smooth Motor power 2.2Kw

Single Auger Plodder model ST180A, capacity 100-150Kg/h

Designed with screw auger to extruding milled schistose raw material to soap bar, auger motor 5.5Kw. Equip with heating system in front of mold to heating the raw material and make the soap bar extruded out more smoothly, heating coil power 2.5Kw.

Water circulation inside the inter layer of extruding auger to cooling down machine during running, thus to improve machine stability

The plodder mold decide shape, width and height of finished soap bar

Complete set include stairs and frame, which is easy to install and easy to feed soap noodles into mixer

Small Laundry Soap Making Machine

2. Laundry Soap Cutting Machine Model: FZ40

Press logo on soap bar and cutting soap bar to laundry soaps

Motor power 1.5Kw

Equip with PLC system to control this machine

PLC, touch screen, servo system, inverter, servo gearbox and motor is Delta brand

Cutting length: 60-1000mm adjustable

Max cutting thickness: 50mm Max cutting width: 80mm

Dimension: 820x500x1080mm

Weight: 125Kg

Equip with 2 meters conveyor to collect laundry soap after cutting machine

We can design the mold to make laundry soap under buyer requirement on the soap shape, size, weight and logo will be pressed on the laundry soap bar
