Ring Die Feed Pellet Machine
Ring die pellet machine, an important machine for making animal, livestock, and poultry feed pellets. Horizontal structure; the machine is easy to operate and maintain. Equipped with a conditioner to cook the material, making the final pellets easy for animals to digest. Assembled hammer mill, mixer, cooler, and packing machine can make a feed pellet plant.
Description
Zhengzhou Fanda Machinery Co., Ltd. is one of the leading manufacturers and suppliers of ring die feed pellet machine in China. With abundant experience, we warmly welcome you to buy cheap ring die feed pellet machine for sale here from our factory. For price consultation, contact us.
Ring Die Feed Pellet Machine
The ring die feed pellet machine produces animal, livestock, pet, and poultry feed pellets from corn, soybeans, and other ingredients; each animal type has its own formula.
The ring die feed pellet machine is an important part of the feed pellet production line because making feed pellets usually requires grinding the feedstocks to the required mesh size, mixing the powders evenly according to the formula percentage, and then sending the mixed powder into the pellet machine to make feed pellets.
The ring-diefeed pellet machine is the most popular type for making feed pellets. It uses a horizontal ring-die pellet mill structure and a stainless steel ring die and conditioner.
The conditioner ripens the feedstock before compressing it into pellets; it is usually made of stainless steel because the final pellets are animal feed.
The conditioner needs to connect to a boiler, which supplies steam to ripen the feedstocks; the steam ripens the feedstock in the conditioner, has fuction of sterilization, and makes the final feed easier to digest by animals.
The ring die of the feed pellet machine is made from 4Cr13 stainless steel to ensure the final pellets meet food-grade standards.
The hole diameter determines the final feed pellet diameter. The ring die compression ratio determines the final feed compression ratio. By changing the ring die, one pellet machine can produce different pellet sizes. We can customize the ring die to meet requirements and provide dies for different models of ring die feed pellet mills.
Ring die feed pellet mill advantages
1. The Ring die feed pellet mill adopts a gearbox transmission system, and the high transmission efficiency greatly improves productivity
2. Suitable for making feed pellets for different kinds of animals and livestock.
3. Stainless steel pelletizing chamber, ring die, and conditioner to ensure the high quality of the final feed.
4. Internationally famous brand bearings and oil seals
5. The feeding speed of the feeder auger is controllable.
6. Electric panels equipped with an overload protection system
7. High-wear roller shell made of 20CrMnTi alloy steel
Ring die feed pellet mill technical data
|
1 |
Model |
SZLH250 |
SZLH320 |
SZLH350 |
SZLH420 |
|
2 |
Capacity |
0.5-1.5T/h for feed pellets |
1.5-3T/h for feed pellets |
2-5T/h for feed pellets |
3-12T/h for feed pellets |
|
3 |
Main Power |
15 KW |
37 KW |
55 KW |
110 KW |
|
4 |
Power of Feeding Auger |
0.55 kW |
0.75 kW |
0.75 kW |
1.5 kW |
|
5 |
Power of Conditioner |
2.2KW |
2.2KW |
2.2KW |
5.5KW |
|
6 |
Inner Diameter of Die |
250 mm |
320 mm |
350 mm |
420 mm |
|
7 |
Ring Die Speed |
305 RPM |
305 RPM |
336 RPM |
287 RPM |
|
8 |
Ring Die Material |
4Cr13 (Stainless steel) |
|||
|
9 |
Conditioner speed |
350RPM |
|||
|
10 |
Pellet Size |
Diameter: 3mm, 4mm, 5mm, 6mm, 8mm, 10mm, or as per your requirement |
|||
|
11 |
Roller Number |
2 |
|||
|
12 |
Roller Diameter |
110mm |
145mm |
165mm |
206mm |
|
13 |
Roller shell material |
40CrMnTi, HRC 56-58 |
|||
|
14 |
Main shaft material |
42 CrMnTi |
|||
|
15 |
Pelletizing ratio |
≥95％ |
|||
|
16 |
Percentage of powdered pellets |
≤12% |
|||
|
17 |
Noise |
≤86dB(A) |
≤90dB(A) |
||
|
18 |
Die working temperature |
≤85℃ |
|||
|
19 |
Steam working pressure |
0.1-0.4Mpa |
|||
|
20 |
Steam consumption |
≥0.3t/h |
≥0.4t/h |
||
|
21 |
Steam temperature |
130-150℃ |
|||
