Disc Wood Chipper

Disc wood chipper, a small and easy operate wood chipper, can make much even size chips. Diesel engine and electric motor optional We can add wheels to make it movable

Send Inquiry

Download

Description

Disc Wood Chipper

Disc wood chipper is designed especially for chipping wood logs, bamboo, wood timbers., etc. It is widely used in the pellet production industry, paper industry particle board industry. It can cut wood materials into high-quality wood chips and shavings with flat incisions, even length, and uniform chip thickness.

The disc wood chipper has two kinds, one kind equipped with an electric motor, and the other kind equipped with a diesel engine. We also can add wheels to make the diesel engine type movable.

Product Structure

The Disc wood chipper is made up of the main structure, cutting blades, motor and transmission device, feeding and discharge chute. The wood and other raw materials feed into the feeding chute and then go to the cutting disc, the cutting disc is runs by the transmission of a motor, and the rotating blades will cut the wood and other raw materials into small chips, according to the requirement of different usage of chips, the length and thickness of final chips can be adjusted. For the bigger model disc wood chipper, we are also equipped with a feeding flat conveyor and discharge conveyor to make the operation much easier. The whole machine is controlled by the electric panel, which includes the thermal overload protection system to protect the motor in case of overload.

Product Advantages

1. Complete structure, easy to install, operate, and maintain, only cover a small area to install it.

2. The chipper body is made of high-strength steel, firm, shock-resistant, with less noise.

3. Special design and reliable blade layout, the disc wood chipper works more efficiently to get evenly length and uniform thickness.

4. Easy to adjust the length and thickness of the inal chips.

5. For a big model disc wood chipper we can equip a feeding flat conveyor and discharge conveyor to make the feeding and discharge much easier.

Technical data

Model	BX600	BX680	BX850	BX1000	BX1150	BX1300
Capacity	0.8-1.2	2-3	3-4	4-5	5-6 T/h	6-8
Main motor power	15Kw	22Kw	37Kw	45Kw	55 Kw	75Kw
Disc cutter diameter	600mm	680mm	850mm	1000mm	1150 mm	1300mm
Rotating speed of the cutter	960 rpm	960 rpm	960 rpm	960 rpm	960 rpm	960 rpm
Inlet feeding mouth size	120x120mm	150x150mm	200x200mm	230x230mm	270x270 mm	350x350mm
Blades quantity	4	4	4	4	4	6
Feeding speed	38 m/min	38 m/min	38 m/min	38 m/min	38 m/min	38 m/min
Max process wood diameter	100mm	130mm	180mm	200mm	250 mm	300mm
Feeding flat conveyor length	Not include	Not include	6 meters	6 meters	6 meters	6 meters
Feeding flat conveyor power	Not include	Not include	3 Kw	3 Kw	3 Kw	3 Kw
Discharging belt conveyor length	Not include	Not include	6 meters	6 meters	6 meters	6 meters
Discharging belt conveyor power	Not include	Not include	2.2 Kw	2.2 Kw	2.2 Kw	2.2 Kw
Weight	760Kg	1370Kg	1750Kg	2180Kg	2950 Kg	3450Kg
