Wood Pellet Press

Wood pellet press vertical type wood pelletizer

wood pellet press also called a wood pellet maker or wood pelletizer or wood pellet mill. our wood pellet press is a vertical ring die pellet mill. It's mainly used to form pellets from wood, and other kinds of wood.

Introduction of wood pellet press:

This is a vertical type ring die wood pellet mill which can make biomass fuel pellets from wood materials such as wood logs, tree branches, wood residues, wasted wood, wood chips, sawdust, and other biomass material like EFB, bagasse, straw, agricultural stalk, rice husk, coconut shell, corn cob., etc

This pellet press can pellet the raw material to 6mm, 8mm, 10mm, and 12mm diameter biomas pellet with 600-700kh/m³ bulk density and 4000-5500 kcal heating value, the biomass pellets or wood pellets produced from this pelletizer can be used as fuel for boiler, home heating, power plants it also can be used as bedding for animals. Usually, people make high compression ratio wood pellets used as fuel to burn them, due to the high compression the wood pellets are hard with high density and when burning them there is a large heating value released. Some people make low compression ratio wood pellets used as animal bedding, These kinds of pellets can be matting on the floor of the animal house, due to the low compression so the pellets are not tightened and can absorb the water and brine in the animal house so that to make it easy to clean animal house.

The raw material put into this vertical ring die wood pellet press should be meet the requirement: the size of raw material smaller than the diameter of pellets will be made, usually make 6mm diameter pellets the size of raw material will be 3-5mm if make 8mm diameter pellets the raw material size should <7mm, if make 10mm diameter wood pellets the raw material size <8mm; best moisture of raw material to make wood pellets is 12-15%, the maximum moisture content moisture can intake is 17% if moisture higher than this can not make good quality wood pellets or even can mot make pellets. So, according to this if your raw material size is bigger than 5mm, you need equipment to crush the material before pressing pellets, if the moisture of your raw material is higher than 15% need a dryer to dry them before making pellets.

Technical data of ring die wood pellet press：

The characteristic of the wood pellet press :

It is a kind of ring die wood pelletizer because the machine structure is a vertical type designed.

1. We have a double layer die used on the machine and the main drive adopts the high accuracy gear driving, so the capacity is 20% higher than the belt-driven one.

2. It uses the imported high-quality bearings, and oil seal to make sure high efficiency, stable performance, and low noise of the whole machine.

3. The feeder uses variable-frequency and variable-speed motors to make sure the good quality of the pellet.

4. Advanced world standard compensatory S-shaped coupling with the structure of the novel, compact, safe, low-noise, and low fault.

5. Feeder, conditioner, and chute are made of stainless steel with long service life.

6. It is with magnet and over load protection system, which can protect machine well during production

7. We have different bore diameters of the ring dies for your choice. And the feeder is with a variable speed controlled to meet different outputs requirements.

8. We have an oversized conditioner and a jacked conditioner for choosing to enhance the effect of the pellet condition.

Advantages of the wood pellet press:

1. Vertical structure, the material can fall into the pelleting chamber by gravity, avoid material blocks in the feeding part, easy to feed material;

2. Vertical structure, easy to open the cover to for maintenance and change ring die and rollers, save time on machine maintenance;


3. When the machine running, the rollers are rotating while the ring die is stable, with the rollers running the centrifugal force can force the material to go to the hole of the ring die, improving pelleting efficiency;

4. The gearbox of our vertical ring dies pellet mill is a brand-name gearbox that is strong enough to make wood pellets, the gears, and special designed structure can bring more powerful pressure compared to the commonly used industrial gearbox, and the motor is horizontally installed and connected to the gearbox by coupling so that to improve efficiency and stability.

5. Equipped with automatic lubricator, which can set interval time and grease inject time, thus to inject grease for bearings of roller and main shaft automatically so that to save labor and time on maintenance and improve production efficiency;

6. Double-layer ring die when the holes on one side are worn out can turn ring die to use the holes on the other side, thus extending the lifetime of the ring die and reducing the cost on produce pellets.

7. Pellet mill equipped dust collector to collect dust and vapor from the pelleting chamber;

8. We can calculate the compression ratio of ring die according to your raw material, thus producing better quality pellets;

9. Equipped with electric panel apply soft start to reduce starting amps.

Pre-sale service
Provide customers with the parameters and confirm technical points
Share photos and videos With clients
Show our factory to clients for checking

On-purchase service
Keep clients informed Of the production progress
Send photos to clients before shipment for checking
Arrange the visa for engineers who will go for guide assembly

After-sale service
Training and all-around technical guidance for operation commission
and maintenance
Engineers abroad to guide assembly
Detailed drawings from the front view, vertical view, and side view.

Packing and Shipping

Packaging: Depending on customers' requirements, such as the wooden boxes or Iron crates, etc.
Shipping: Our shipping operator and delivery equipment will be ready on time to ensure goods are shipped based on Sales Order requirements.
