Latest Generation Biomass Wood Sawdust Rice Husk Straw Wood Pellet Mill

Zhengzhou Fanda Machinery Co., Ltd. is one of the leading manufacturers and suppliers of latest generation biomass wood sawdust rice husk straw wood pellet mill in China. With abundant experience, we warmly welcome you to buy cheap latest generation biomass wood sawdust rice husk straw wood pellet mill for sale here from our factory. For price consultation, contact us.

The raw materials for the Latest Generation Biomass Wood Sawdust Rice Husk Straw Wood Pellet Mill:

The vertical ring die pellet machine is designed to make wood pellets and other kinds of biomass fuel pellets from wood sawdust and other kinds of biomass material such as wood chips, wood shavings, wood logs, tree branches, wood residues, wasted wood, wood blocks, rice husk, sunflower husk, peanut shell, EFB, sugarcane bagasse, stalk, straw, etc.

The biomass material fed into this pellet machine should be sized to < 6 mm (similar to sawdust) and have a moisture content of 12%-15%.

Features of the Latest Generation Biomass Wood Sawdust Rice Husk Straw Wood Pellet Mill:

1. The vertical ring die biomass pellet machine consists of a gearbox, motor, spindle, ring die, roller, pelletizer, feed chute, discharge chute, automatic oiler, oil pump, bag dust collector, and electrical panel.

2. The gearbox is independently developed and designed by our company and comes with a lifetime warranty. The gearbox housing is welded with 24 mm-thick steel plates and undergoes strict pressure and water pressure tests before leaving the factory. It uses high-precision gear transmission, three-stage transmission, and two-stage reduction. It includes an automatic oil circulation system to extend the gearbox's service life and ensure the pellet machine's stable operation.

3. The gearbox adopts a large-capacity design, and the two independent boxes can hold 200 kg of gear oil together, which effectively avoids the problem of gear oil overheating caused by long-term operation of the pellet machine.

4. The gearbox adopts high-quality cast steel gears, which are completely immersed in gear oil and run at room temperature without wear. The gearbox uses heavy-duty pressure bearings and well-known brands such as HRB, ZCZ, and LYC.

5. The large-capacity box can better lubricate and cool the bearings, thereby extending the service life of the bearings.

6. Vertical installation of motor: The main motor of this machine is a six-pole motor, which is installed vertically to ensure efficient and stable operation of the machine. Its key feature is that the mounting holes are centered on the output shaft and evenly distributed, ensuring greater power and stability.

7. The pellet machine is equipped with a dust collection system: The system consists of a fan and a bag dust collector, which is located on one side of the working chamber of the pellet machine and can be freely adjusted according to the working time. Its main function is to help discharge dust and excess steam from the pellet machine working chamber.

8. Automatic lubrication system for rollers: The independently installed oiling device adopts a piston drive to inject high-temperature-resistant grease into the roller bearings evenly. An independent electronic control system controls the lubrication system. The control panel lets you adjust the oiling frequency and time. The system runs automatically and can be maintained without stopping. The gearbox oil pump circulates gear oil to lubricate the spindle bearings.
To extend spindle life, we increased the spindle diameter from 120mm to 160mm. We upgraded to a spline shaft connection, allowing the spindle to drive the working parts with zero error and improving transmission efficiency.

9. The discharging system adopts the most advanced discharging design, placing the rotating parts outside, which completely solves the corrosion and rusting problems caused by steam and high temperature in the original upper discharging pellet machine.

10. The ring die is made of alloy steel with a hardness of HRC 55 or above, which prolongs the service life of the accessories. The ring die uses an upper-and-lower double-layer design. When working, the material is discharged from the lower layer. The upper and lower layers can share the same aperture to extend the service life. One ring die can be customized with two different apertures, saving the cost of purchasing separate molds for producing pellets of different particle sizes.

11. The outer diameter of the roller is increased from 200mm to 265mm, which makes the contact surface between the roller and the ring die larger and ensures higher output of the machine. The larger bearing works well with the roller's automatic oiling function, extending the roller's service life.

12. The number of rollers is reduced from four to two, which not only saves the cost of use but also facilitates replacement and maintenance. We use a combination of sealing rings and sealing covers to ensure that the rollers are completely sealed during operation and will not be damaged by dust or material entering. The granulating chamber uses a stainless steel shell to prevent corrosion and rust during long-term operation. The pelletizer includes an electrical panel, and the main motor uses star-delta starting. The electrical panel allows easy control of the entire pelletizer.

Technical Data:
