Ring Die Mold Matrix For Feed Pellet Machine

Zhengzhou Fanda Machinery Co., Ltd. is one of the leading manufacturers and suppliers of ring die mold matrix for feed pellet machine in China. With abundant experience, we warmly welcome you to buy cheap ring die mold matrix for feed pellet machine for sale here from our factory. For price consultation, contact us.

The ring die is also called a mold or matrix; it is a spare/wear part for a horizontal ring die pellet mill. During pellet mill operation, the ring die holes wear out due to high-strength compression.

Compression ratio is important for the ring die; it is the ratio of the hole diameter to the hole's effective compression length. The hole's effective compression length and the compression ratio determine the compression time as raw material passes through the hole; different bulk-density raw materials require different ring-die compression ratios.

The compression ratio determines hardness, color, and pelletizing ratio; in other words, it determines final pellet quality. If the ring die compression ratio is too low for the raw material, the pellets will be loose or won't form when the material passes through the holes. If the compression ratio is too high, the pellet surface may be black, hardness may be too high, or the material may block inside the holes and fail to pass.

For low-bulk-density raw material, usually choose a higher compression-ratio ring die; for high-bulk-density raw material, usually choose a lower compression-ratio ring die.

To produce white pellets with shiny surfaces and good hardness, choose the right compression ratio for your ring die; it is very important.

1. We manufacture all kinds of ring dies for different ring die pellet mill models, such as 250, 320, 350, 400, 420, 508, 568, 678, and 768.

2. We can manufacture ring dies with different compression ratios to meet client requirements, or our engineer can suggest a compression ratio based on your raw material.l

3. We can manufacture ring dies for both feed pellets and fuel pellets/wood pellets.

4. For wood pellets or biomass fuel pellets, our ring die uses 42CrMnTi raw material. The ring die hardness is good, and after heat treatment, the hole is smooth,h and the ring die lifetime is longer than before

5. For feed pellets, our ring die uses 4Cr13 stainless steel to make sure the final pellets are food-grade

6. We accept OEM ring dies for clients for any size with your drawing

Ring die drilling holes for horizontal ring die pellet mill
