Pellet Packing Machine

Pellet packing machine Pellet packing machine is an quantitive packing machine, machine include material tank, weighing device, sensor, bag clamp device, heat sealer, sewing sealer, sealing conveyor, electric control panel. Material feed into tank, the weighing device and sensor will work under......

Send InquiryChat Now

Pellet packing machine


Our quantitative pellet packing machines are new generation of self-developed quantitative packaging equipment after our digestion and absorption of foreign advanced technologies. Its salient features are: accurate, low failure rate, wide adaptation and flexible combination.

This pellet packing machines are designed by module, discharging with vibration and the weighing hoppers work alternately. You can also choose automatic feeding machines and bag-making machines according to need, so as to further improve packaging efficiency, quantitative accuracy and the degree of automation.

The machine in this series adopts microcomputer control technology, and the weighing units are controlled independently without disturbing each other. It is stable and reliable with high repeatability and low noise. The whole machine is made of high quality stainless steel with high corrosion resistance, and will not contaminate materials. Changes to specifications and materials can be realized through modifying the parameters by the control panel instead of mechanical adjustments. The machine has such functions as real-time weight display, dynamic measurement weighing, automatic error correction, tolerance alarm, level control, counting, data protection and so on. It is applicable for packing of small and irregular granular materials including: detergent, snack foods, salt, sugar, spices, seeds, rice, wheat, corn, wood pellets, feed pellets and so on.

Pellet packing machine is an quantitive packing machine, the machine include material tank, weighing device, sensor, bag clamp device, heat sealer, sewing sealer, sealing conveyor, electric control panel. Material feed into tank, the weighing device and sensor will work under the control of electric panel to weight to the set value, after bags clamp to the clamp device the hopper discharge pellets to bags, then use sealer to sealing the bags.

From the electric control panel can set the weight want to pack, the weighing device and sensor can weight to the set weight with less than 0.2%F.S tolerance.

This pellet packing machine can pack plastic bags and woven bags, as for sealer we have heat sealer to seal the plastic bags and stitching sewing sealer to seal the woven bags.


Pellet packing machine technical data:

Model

50A

100A

Weighting range

5-25Kg

10-100Kg

Tolerance

10-20g

10-20g

Error

0.2%F.S

0.2%F.S

Packing Scale Power

0.37 Kw

0.37 Kw

Packing speed

≤300 bags/h (3-4 bags/minute)

≤300 bags/h (3-4 bags/minute)

Conveyor length

2700mm

2700mm

Conveyor width

400mm

400mm

Belt width

320mm

320mm

Sealing conveyor power

0.37 Kw

0.37 Kw

Sealing type

Heat sealer and sewing machine

Heat sealer and sewing machine

Sealing length

600mm

600mm

Sealing width

8mm

8mm

Film thickness

0.01-0.12mm

0.01-0.12mm

Machine weight

440kg

580kg
